F Series-FSO 960X960mm

8.1
Home > Product > outdoor
F Series-FSO 960X960mm
F Series-FSO 960X960mm
F Series-FSO 960X960mm
Description

This high-performance 960x960mm outdoor LED screen combines environmentally friendly 200W average power efficiency, excellent 9500:1 contrast ratio and vivid colors. Its ultra-thin aluminum frame allows for flexible stacking and hanging installation, and its 140° wide viewing angle supports flat and curved 3D configurations. IP65 waterproof rating and advanced die-cast aluminum fabric mesh ensure long-lasting durability.

Chat with us Leave a message
Applicable Scenarios：

Suitable for outdoor advertising, markets, squares, theme parks, stadiums, etc.

Product Parameters:
Classification Mode TEST-FSO-96-667
Module Specification Pixel Pitch 6.67 mm
Pixel density 22500dot/㎡
LED Type SMD2727(1R1G1B)
Module Size 480*320mm
Module Resolution 72*48 dot
Cabinet Specification Cabinet Size 960*960*77mm
Cabinet Resolution 144*144 dot
Material Aluminim Profile
Cabinet Weight 28 kg
Display Specification Brightness ≥ 7500cd/㎡
Viewing Angle HV 140°/140°
Contrast Ratio 9500:1
Current range high ≥5m
Color Temperature 2000-10000K（Adjustable）
Fresh Rate ≥ 3840 Hz
Gray Grade 14 bit+
Scanning Mode 1/6S
IP Rating IP65
Max Consumption 650W/㎡
Average Power Consumption
(W/㎡)		 200
Working Input AC 110-240V,50-60Hz
Energy Consumption Mode Common anode energy-saving
Control Way Computer syschronous control
Input Signal Composite Video,DVI,VGA,HDMI,HDSDI
Working temperature -20-+60
Working humidity 10%-95%RH
Application environment 10-90%RH
