MIP usually refers to MMemory-in-PixelM technology. This is a pixel design that integrates memory, allowing the driver’s circuit and memory to be combined within each pixel, thereby improving the performance and the image’s quality of the display.
Widely used in private theaters, lecture halls, conference rooms, music halls, XR virtual filming, data centers, and other scenarios.
| Classification | Name | Demand |
| Technical parameter | Pixel Pitch (mm) | FCM-P0.9375 |
| Pixel Density (pixels/m²) | 1,137,778 | |
| LED type | Mip- 0303 (0.3mm*0.3mm) |
|
| Module qty/ Cabinet qty（pcs） | 8/1 | |
| Module Size (mm) | 150*168.75 | |
| Module Composition | 1R1G1B | |
| Module Flatness (mm) | ≤0.05 | |
| Refresh Rate (Hz) | 7680 | |
| Frame Rate (Hz) | 60 | |
| Gray Level | 22 | |
| Cabinet Material | Die-cast aluminum | |
| Cabinet Weight (KG/PCS) | 4.4±10% | |
| Cabinet Size (mm) | 600*337.5 | |
| Cabinet Thickness (mm) | ≤23 | |
| Cabinet Resolution (Pixel) | 640*360 | |
| IP Rate | IP45 | |
| Maintenance Mode | Front maintenance | |
| Signal Source | HDMI,DP,DVI,etc | |
| Optical characteristic | Brightness (nits) | 1300 |
| Color Temperature (K) | 9500 | |
| View Angle | ≥160° | |
| Contrast Ratio | 20000:1 | |
| Electrical parameter | Output Voltage (V) | 5 |
| Reliability Testing | +85℃(85%RH)/-20℃, electrical performance normal after 72 hours of testing. |
|
| Maximum Power Consumption (W/㎡） | 400 | |
| Average Power Consumption (W/㎡) | 200 | |
| Module supply voltage DC（V） | 2.8 | |
| Module maximum power consumption（W/PCS） | 6.25 ± 10% | |
| Usage parameter | Typical LED Lifetime (H) | 100000 |
| Working Temperature （°C） |
-20℃ ~ +80℃ | |
| Working humidity | 10% ~ 90%RH | |
| Storage Temperature （°C） |
25±3 | |
| Signal Interface Mode | AV, S-Video, VGA, DVI, HDMI, SDI, YPbPr | |
| Operating system | Microsoft | |
| Receiving card | Nova/Colorlight | |
| Control distance | CAT5 line: < 100m; Single-mode optical fiber: < 10km | |
| Connector | Quick lock |
